Top Bottom (Style F) Template & Dieline Generator
Top Bottom Style F is a tray-pattern template with extended side returns and diagonal creases at each corner.
The flat layout wraps narrow folding bands around a rectangular center and adds projecting joining sections. This gives it a different corner treatment from Styles D and E. Check the folding order and accumulated material thickness before deciding on a corresponding lid or cover size.
Sign in to edit dimensions. PDF and DXF downloads use export credits.
| Categories | Top Bottom Box |
|---|---|
| Customizable | Dimensions and available construction controls |
| Export | PDF and DXF with export credits |
How to use this template
1Open template
Open the Top Bottom (Style F) template in Carton Maker.
2Adjust dimensions
Sign in and adjust the dimensions and available construction controls.
3Review and export
Check the dieline, preview the fold, and export as PDF or DXF.
Make and check a physical sample with your intended material before production.
