Straight Tuck (Panel 3) Template & Dieline Generator
Straight Tuck Panel 3 places both main top and bottom tuck flaps on the third panel of a four-panel carton.
In the preview, the broad flaps are on the right-hand main panel rather than the first one. The folded product shape may resemble Panel 1, but the print-panel and opening arrangement differs. Use this exact dieline for artwork and check the joining strip and dust-flap clearances in a sample.
Sign in to edit dimensions. PDF and DXF downloads use export credits.
| Categories | Tuck End Box, Medicine Box |
|---|---|
| Customizable | Dimensions and available construction controls |
| Export | PDF and DXF with export credits |
How to use this template
1Open template
Open the Straight Tuck (Panel 3) template in Carton Maker.
2Adjust dimensions
Sign in and adjust the dimensions and available construction controls.
3Review and export
Check the dieline, preview the fold, and export as PDF or DXF.
Make and check a physical sample with your intended material before production.
